Muscle
|
 Click on image for larger view |
|
|
Name
|
Triceps brachii
|
|
|
Subdivision
|
Lateral head
|
|
|
Muscle Anatomy
|
||
|
Origin
|
Lateral and posterior surfaces of proximal 1/2 of body of humerus and lateral intramuscular septum. | |
|
Insertion
|
Posterior surface of olecranon process of ulna and
antebrachial fascia.
|
|
|
Function
|
Extension of the elbow joint.
|
|
|
Recommended sensor placement procedure
|
||
|
Starting posture
|
Sitting with the shoulder at approximately 90 degrees
abduction with the arm 90 degrees flexed and the palm of the hand
pointing downwards.
|
|
|
Electrode size
|
Maximum size in the direction of the muscle fibres:
10 mm.
|
|
|
Electrode distance
|
20 mm
|
|
|
Electrode placement
|
||
|
- location
|
Electrodes need to be placed at 50 % on the line
between the posterior crista of the acromion and the olecranon at
2 finger widths lateral to the line.
|
|
|
- orientation
|
In the direction of the line between the posterior
crista of the acromion and the olecranon process.
|
|
|
- fixation on the skin
|
(Double sided) tape / rings or elastic band.
|
|
|
- reference electrode
|
On / around the wrist.
|
|
| Clinical test | Extend the elbow while applying pressure to the forearm in the direction of flexion. | |
| Remarks |
The SENIAM guidelines include a separate sensor
placement procedure recommendation for the long head of triceps
brachii..
|
|
