Muscle
|
 Click on image for larger view |
|
|
Name
|
Soleus
|
|
|
Subdivision
|
||
|
Muscle Anatomy
|
||
|
Origin
|
Posterior surfaces of the head of the fibula and proximal 1/3 of its body, soleal line and middle 1/3 of medial border of tibia and tendinous arch between tibia and fibula. | |
|
Insertion
|
With tendon of gastrocnemius into posterior surface
of calcaneus.
|
|
|
Function
|
Plantar flexion of the ankle joint.
|
|
|
Recommended sensor placement procedure
|
||
|
Starting posture
|
Sitting with the knee approximately 90 degrees flexed
and the heel / foot of the investigated leg on the floor.
|
|
|
Electrode size
|
Maximum size in the direction of muscle fibres:
10 mm.
|
|
|
Electrode distance
|
20 mm.
|
|
|
Electrode placement
|
||
|
- location
|
The electrodes need to be placed at 2/3 of the line
between the medial condylis of the femur to the medial malleolus.
|
|
|
- orientation
|
In the direction of the line between the medial
condylis to the medial malleolus.
|
|
|
- fixation on the skin
|
(Double sided) tape / rings or elastic band.
|
|
|
- reference electrode
|
On / around the ankle or the proc. spin. of C7.
|
|
| Clinical test | Put a hand on the knee and keep / push the knee downward while asking the subject / patient to lift the heel from the floor. | |
| Remarks | ||
