Muscle
|
 Click on image for larger view |
|
|
Name
|
Quadriceps Femoris
|
|
|
Subdivision
|
rectus femoris
|
|
|
Muscle Anatomy
|
||
|
Origin
|
Straight head from anterior inferior iliac spine. Reflected head from groove above rim of acetabulum. | |
|
Insertion
|
Proximal border of the patella and through patellar
ligament.
|
|
|
Function
|
Extension of the knee joint and flexion of the hip
joint.
|
|
|
Recommended sensor placement procedure
|
||
|
Starting posture
|
Sitting on a table with the knees in slight flexion
and the upper body slightly bend backward.
|
|
|
Electrode size
|
Maximum size in the direction of the muscle fibres:
10 mm.
|
|
|
Electrode distance
|
20 mm.
|
|
|
Electrode placement
|
||
|
- location
|
The electrodes need to be placed at 50% on the line
from the anterior spina iliaca superior to the superior part of
the patella
|
|
|
- orientation
|
In the direction of the line from the anterior spina
iliaca superior to the superior part of the patella.
|
|
|
- fixation on the skin
|
(Double sided) tape / rings or elastic band.
|
|
|
- reference electrode
|
On / around the ankle or the proc. spin. of C7.
|
|
| Clinical test | Extend the knee without rotating the thigh while applying pressure against the leg above the ankle in the direction of flexion. | |
| Remarks |
The SENIAM guidelines include also a separate sensor
placement procedure for the vastus medialis and the vastus lateralis
muscle.
|
|
