Muscle
|
 Click on image for larger view |
|
|
Name
|
Multifidus
|
|
|
Subdivision
|
|
|
|
Muscle Anatomy
|
||
|
Origin
|
Spinous processes L1 - L5 | |
|
Insertion
|
Massillary processes L4-S1 Iliaccresr, dorsal surface of sacrum | |
|
Function
|
Extension
|
|
|
Recommended sensor placement procedure
|
||
|
Starting posture
|
Prone with the lumbar vertebral columns slightly
flexed.
|
|
|
Electrode size
|
Maximum size in the direction of the muscle fibres:
10 mm.
|
|
|
Electrode distance
|
Max. 20 mm.
|
|
|
Electrode placement
|
||
|
- location
|
Electrodes need to be placed on and aligned with
a line from caudal tip posterior spina iliaca superior to the interspace
between L1 and L2 interspace at the level of L5 spinous process
(i.e. about 2 - 3 cm from the midline).
|
|
|
- orientation
|
In the direction of the line described above.
|
|
|
- fixation on the skin
|
(Double sided) tape / rings.
|
|
|
- reference electrode
|
On the proc. spin. of C7.
|
|
| Clinical test | Lifting the trunk from a prone position. | |
| Remarks | ||
