Muscle
|
 Click on image for larger view |
|
|
Name
|
Gluteus
|
|
|
Subdivision
|
Medius
|
|
|
Muscle Anatomy
|
||
|
Origin
|
External surface of ilium between iliac crest and posterior gluteal line dorsally, and anterior gluteal line ventrally, gluteal aponeurosis. | |
|
Insertion
|
Oblique ridge on lateral surface of greater trochanter
of femur.
|
|
|
Function
|
Abduction of the hip joint. The anterior fibres
medially rotate and may assist in flexion of the hip joint; the
posterior fibres laterally rotate and may assist in extension.
|
|
|
Recommended sensor placement procedure
|
||
|
Starting posture
|
Lying on the side on a table.
|
|
|
Electrode size
|
Maximum size in the direction of the muscle fibres:
10 mm.
|
|
|
Electrode distance
|
20 mm.
|
|
|
Electrode placement
|
||
|
- location
|
Electrodes need to be placed at 50% on the line
from the crista iliaca to the trochanter.
|
|
|
- orientation
|
In the direction of the line from the crista iliaca
to the trochanter.
|
|
|
- fixation on the skin
|
(Double sided) tape / rings or elastic band.
|
|
|
- reference electrode
|
On the proc. spin. of C7 or on / around the wrist
or on / around the ankle.
|
|
| Clinical test | Lying on the side with the legs spread against manual resistance (holding the ankles) | |
| Remarks |
The SENIAM guidelines include also a separate sensor
placement procedure for the gluteus maximus muscle.
|
|
